Пластины ATG

Пластины ATG

Пластины ATG для обработки канавок малого размера

Вид пластины Обозначение Пластины Условия обработки ● Хорошие  Средние  Плохие
● ● ● ●
Режимы резания Размеры P M K N
Обработка канавок CDX CW RE AC230P AP301U AP330M AP301U AP330M AC230P AP301U AW100K
f (мм/об)
*ATG 32R/L033T08-R005 0.03-0.08 0.8 0.33 0.05   ●   ●     ●
ATG 32R/L050T12-R005 0.03-0.08 1.2 0.50 0.05   ●   ●     ●
ATG 32R/L075T20-R005 0.03-0.08 2.0 0.75 0.05   ●   ●     ●
ATG 32R/L095T20-R005 0.03-0.08 2.0 0.95 0.05   ●   ●     ●
ATG 32R/L100T20-R005 0.03-0.08 2.0 1.00 0.05   ●   ●     ●
ATG 32R/L110T20-R005 0.03-0.08 2.0 1.10 0.05   ●   ●     ●
ATG 32R/L120T20-R005 0.03-0.08 2.0 1.20 0.05   ●   ●     ●
ATG 32R/L125T20-R020 0.04-0.09 2.0 1.25 0.20   ●   ●     ●
ATG 32R/L130T20-R020 0.04-0.09 2.0 1.30 0.20   ●   ●     ●
ATG 32R/L140T25-R020 0.04-0.09 2.5 1.40 0.20   ●   ●     ●
ATG 32R/L145T25-R020 0.04-0.09 2.5 1.45 0.20   ●   ●     ●
ATG 32R/L150T25-R020 0.04-0.09 2.5 1.50 0.20   ●   ●     ●
ATG 32R/L160T25-R020 0.04-0.09 2.5 1.60 0.20   ●   ●     ●
ATG 32R/L170T25-R020 0.04-0.09 2.5 1.70 0.20   ●   ●     ●
ATG 32R/L175T25-R020 0.04-0.09 2.5 1.75 0.20   ●   ●     ●
ATG 32R/L200T25-R020 0.04-0.09 2.5 2.00 0.20   ●   ●     ●
ATG 32R/L225T25-R020 0.04-0.09 2.5 2.25 0.20   ●   ●     ●
ATG 32R/L250T25-R020 0.05-0.10 2.5 2.50 0.20   ●   ●     ●
ATG 32R/L300T25-R020 0.05-0.10 2.5 3.00 0.20   ●   ●     ●
ATG 43R/L100T20-R010 0.03-0.08 2.0 1.00 0.10   ●   ●     ●
ATG 43R/L125T20-R010 0.04-0.09 2.0 1.25 0.10   ●   ●     ●
ATG 43R/L125T20-R020 0.04-0.09 2.0 1.25 0.20   ●   ●     ●
ATG 43R/L130T30-R010 0.04-0.09 3.0 1.30 0.10   ●   ●     ●
ATG 43R/L130T30-R020 0.04-0.09 3.0 1.30 0.20   ●   ●     ●
ATG 43R/L140T35-R010 0.04-0.09 3.5 1.40 0.20   ●   ●     ●
ATG 43R/L145T35-R020 0.04-0.09 3.5 1.45 0.20   ●   ●     ●
ATG 43R/L150T35-R010 0.04-0.09 3.5 1.50 0.10   ●   ●     ●
ATG 43R/L150T35-R020 0.04-0.09 3.5 1.50 0.20   ●   ●     ●
ATG 43R/L170T35-R020 0.04-0.09 3.5 1.70 0.20   ●   ●     ●
ATG 43R/L175T35-R020 0.04-0.09 3.5 1.75 0.20   ●   ●     ●
ATG 43R/L185T35-R020 0.04-0.09 3.5 1.85 0.20   ●   ●     ●
ATG 43R/L195T35-R020 0.04-0.09 3.5 1.95 0.20   ●   ●     ●
ATG 43R/L200T35-R010 0.04-0.09 3.5 2.00 0.10   ●   ●     ●
ATG 43R/L200T35-R020 0.04-0.09 3.5 2.00 0.20   ●   ●     ●
ATG 43R/L225T35-R020 0.04-0.09 3.5 2.25 0.20   ●   ●     ●
ATG 43R/L230T35-R020 0.05-0.10 3.5 2.30 0.20   ●   ●     ●
ATG 43R/L250T50-R010 0.05-0.10 5.0 2.50 0.10   ●   ●     ●
ATG 43R/L250T50-R030 0.05-0.10 5.0 2.50 0.30   ●   ●     ●
ATG 43R/L265T50-R030 0.05-0.10 5.0 2.65 0.30   ●   ●     ●
ATG 43R/L280T50-R030 0.05-0.10 5.0 2.80 0.30   ●   ●     ●
ATG 43R/L300T50-R010 0.05-0.10 5.0 3.00 0.10   ●   ●     ●
ATG 43R/L300T50-R030 0.05-0.10 5.0 3.00 0.30   ●   ●     ●
ATG 43R/L325T50-R030 0.05-0.10 5.0 3.50 0.30   ●   ●     ●
ATG 43R/L330T50-R030 0.05-0.12 5.0 3.30 0.30   ●   ●     ●
ATG 43R/L350T50-R010 0.05-0.12 5.0 3.50 0.10   ●   ●     ●
ATG 43R/L350T50-R030 0.05-0.12 5.0 3.50 0.30   ●   ●     ●
ATG 43R/L400T50-R010 0.05-0.12 5.0 4.00 0.10   ●   ●     ●
ATG 43R/L400T50-R040 0.05-0.12 5.0 4.00 0.40   ●   ●     ●
ATG 43R/L430T50-R040 0.05-0.12 5.0 4.30 0.40   ●   ●     ●
ATG 43R/L450T50-R040 0.05-0.12 5.0 4.50 0.40   ●   ●     ●
ATG 43R/L480T50-R040 0.05-0.12 5.0 4.80 0.40   ●   ●     ●
ATG 32R/L050T20-R025 0.03-0.08 1.2 0.50 0.25   ●   ●     ●
ATG 32R/L100T20-R050 0.03-0.08 2.0 1.00 0.50   ●   ●     ●
ATG 32R/L150T25-R075 0.04-0.09 2.5 1.50 0.75   ●   ●     ●
ATG 32R/L200T25-R100 0.04-0.09 2.5 2.00 1.00   ●   ●     ●
ATG 32R/L300T25-R150 0.05-0.10 2.5 3.00 1.50   ●   ●     ●
ATG 32R/L100T20-R050 0.03-0.08 2.0 1.00 0.50   ●   ●     ●
ATG 32R/L150T35-R075 0.04-0.09 3.5 1.50 0.75   ●   ●     ●
ATG 32R/L200T35-R100 0.04-0.09 3.5 2.00 1.00   ●   ●     ●
ATG 32R/L250T35-R125 0.05-0.10 5.0 2.50 1.25   ●   ●     ●
ATG 32R/L300T40-R150 0.05-0.10 5.0 3.00 1.50   ●   ●     ●
ATG 32R/L400T50-R200 0.05-0.12 5.0 4.00 2.00   ●   ●     ●



Заказать можно по телефонам
